| Display System |
3 LCD system |
| Size of effective display area |
0.63” (16mm) x 3 BrightEra LCD Panel Aspect ratio 4:3 |
| Number of pixels |
2,359,296 (1024×768 x 3) pixels |
| Focus |
Manual |
| Zoom Powered/Manual |
Manual |
| Zoom – Ratio |
Approx. x 1.3 |
| Throw Ratio |
1.37:1 to 1.80:1 |
| Type |
Ultra high-pressure mercury lamp |
| Wattage |
225 W type |
| Filter cleaning/replacement cycle (Max.) |
10,000H |
| Screen size |
30″ to 300″ (0.76 m to 7.62 m) (measured diagonally) |
| Lamp mode: High |
3600 lm |
| Lamp mode: Standard |
2500 lm |
| Lamp mode: Low |
1900 lm |
| Computer signal input |
Maximum display resolution: 1600 x 1200 dots, fV:60Hz |
| Video signal input |
NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i,1080/60p, 1080/50p |
| Colour system |
NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60 |
| Vertical |
+/-30 degrees |
| INPUT OUTPUT (Computer/Video/Control) |
|
| INPUT A |
RGB / Y PB PR inputconnector: Mini D-sub 15 pin female Audio input connector: Stereo mini jack |
| INPUT B |
RGB input connector: Mini Dsub 15 pin female Audio input connector: Stereo mini jack |
| INPUT C |
HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support |
| INPUT D |
HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support |
| S VIDEO IN |
S Video input connector: Mini DIN 4-pin |
| VIDEO IN |
Video input connector: Phono jack |
| OUTPUT |
MONITOR output connector: Mini D-sub 15 pin female Audio output connector: Stereo mini jack |
| REMOTE |
D-sub 9-pin male/RS232C |
| LAN |
RJ-45, 10BASE-T/100BASE-TX |
| USB |
TYPE – A |
| USB |
TYPE – B |
| MICROPHONE IN |
Microphone jack: Mini Jack |
| Lamp mode: Low |
29db |
|
|
| AC 100 V to 120 V |
5.5W (LAN) 6.0W (optional WLAN module) 6.2W (ALL Terminals and Networks Connected, when “Standby Mode” is set to “Standard”) |
| AC 220 V to 240 V |
5.8W (LAN) 6.3W (optional WLAN module) 6.6W (ALL Terminals and Networks Connected, when “Standby Mode”is set to “Standard”) |
| Mass Approx. |
3.9kg (8.6 lb) |
|
|
|
|
