Specifications
| Display System | 3 LCD |
|
Display device |
|
| Size of effective display area |
0.59” (15 mm) x 3 BrightEra LCD Panel, Aspect ratio 16:10
|
| Number of pixels | 3,072,000 (1280×800 x 3) pixels |
| Projection lens | |
|
Focus
|
Manual |
|
Zoom – Powered/Manual
|
Manual |
|
Zoom – Ratio
|
Approx. x 1.03 |
|
Throw Ratio
|
0.27:1-0.27:1 (0.267:1-0.274:1) |
|
Lens shift – Powered/Manual
|
Manual |
|
Lens shift – Range Vertical
|
+/- 3.7% |
|
Lens shift – Range Horizontal
|
+/- 2.3% |
| Light source | |
|
Type
|
Ultra high-pressure mercury lamp |
|
Wattage
|
225 W type |
| Recommended lamp replacement time *3 | |
|
Lamp mode: High
|
4000 H |
|
Lamp mode: Standard
|
6000 H |
|
Lamp mode: Low
|
10000 H |
|
Filter cleaning/replacement cycle (Max.)
|
|
| Filter cleaning/replacement cycle (Max.) | Same time as the lamp replacement is recommended |
| Screen size | |
| Screen size | 65″-110″ (measured diagonally) |
| Light output *1 | |
| Lamp mode: High | 3300 lm |
| Lamp mode: Standard | 2300 lm |
| Lamp mode: Low | 1900 lm |
| Color light output *1 | |
|
Lamp mode: High
|
3300 lm |
|
Lamp mode: Standard
|
2300 lm |
|
Lamp mode: Low
|
1900 lm |
| Contrast ratio (full white / full black) *2 | |
|
Contrast ratio (full white / full black)
|
3000:1 |
| Speaker | |
| Speaker | 16W (monaural) |
| Displayable scanning frequency | |
| Horizontal | 15 kHz to 92 kHz |
| Vertical | 48 Hz to 92 Hz |
| Display resolution | |
|
Computer signal input
|
Maximum display resolution: UXGA 1600 x 1200 dots*3 |
|
Video signal input
|
480/60i, 480/60p, 575/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p |
| Color system | |
|
Color system
|
NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N,PAL-60 |
| Keystone correction (Max.) *4 | |
|
Vertical
|
+/-5 degrees |
|
INPUT-OUTPUT (Computer/Video/Control) |
|
|
INPUT A
|
RGB / Y PB PR input connector: Mini D-sub 15-pin (female) Audio input connector: Stereo mini-jack |
|
INPUT B
|
RGB input connector: Mini D-sub 15-pin (female) Audio input connector: Stereo mini-jack |
|
INPUT C
|
HDMI input connector: HDMI 19-pin, HDCP support HDCP support, Audio input connector: HDMI audio support |
|
S VIDEO IN
|
S Video input connector: Mini DIN 4-pin |
|
VIDEO IN
|
Video input connector: pin jack |
|
OUTPUT
|
Monitor output connector: Mini D-sub 15-pin (female) Audio output connector: Stereo mini jack (variable out) |
|
REMOTE
|
D-sub 9-pin male/RS232C |
|
LAN
|
RJ-45, 10BASE-T/100BASE-TX |
|
USB
|
Type-A |
|
USB
|
Type-B |
|
MICROPHONE IN
|
Microphone input: Mini jack |
| Acoustic noise *5 | |
|
Lamp mode: Low
|
28 dB |
| Operating temperature / Operating humidity | |
|
Operating temperature / Operating humidity
|
0°C to 40°C (32°F to 104°F) / 20% to 80% (no condensation) |
| Storage temperature / Storage humidity | |
|
Storage temperature / Storage humidity
|
-10°C to +60°C (14°F to +140°F) / 20% to 80% (no condensation) |
| Power requirements | |
|
Power requirements
|
AC 100 V to 240 V, 3.3 A to 1.5 A, 50 Hz / 60 Hz |
| Power consumption | |
|
AC 100 V to 120 V
|
Lamp mode: High: 330 W |
|
AC 220 V to 240 V
|
Lamp mode: High: 320 W |
| Power Consumption (Standby Mode)
AC 220 V to 240 V
0.5 W (when “Standby mode” is set to “Low”)
|
|
|
AC 100 V to 120 V
|
0.5 W (when “Standby mode” is set to “Low”) |
| Power Consumption (Networked Standby Mode) | |
|
AC 100 V to 120 V
|
5.3 W (LAN) 5.9 W (optional WLAN module) 6.1 W (All Terminals and Networks Connected) (when “Standby Mode” is set to “Standard”) |
|
AC 220 V to 240 V
|
5.6 W (LAN) 6.2 W (optional WLAN module) 6.4 W (All Terminals and Networks Connected) (when “Standby Mode” is set to “Standard”) |
| Standby Mode / Networked Standby Mode Activated | |
|
Standby Mode / Networked Standby Mode Activated
|
After about 10 minutes |
| Wireless Network(s) On/Off Switch | |
|
Wireless Network(s) On/Off Switch
|
1) Press the MENU button, then select [Connection/Power] 2) [WLAN Settings] 3) [WLAN Connection] 4) Select On or Off |
| Heat dissipation | |
|
AC 100 V to 120 V
|
1126 BTU |
|
AC 220 V to 240 V
|
1092 BTU |
| Dimensions (W x H x D) | |
|
Dimensions (W x H x D) (without protrusions)
|
Approx. 372 x 138 x 382 mm (14 21/32 x 5 7/16 x 15 1/32 inches) |
| Mass | |
|
Mass
|
Approx. 6.0kg (13lb) |
| Supplied accessories | |
|
Remote commander
|
RM-PJ8 |
| Notes | |
|
*1
|
The values are estimated.
|
|
*2
|
This value is average with lamp dimming. |
|
*3
|
The figures are approximate. They vary depending on the environment or how the projector is. |
|
*4
|
The picture quality may deteriorate when the V Keystone function is used for it is an electrical. |
|
*5
|
The figures are approximate. They vary depending on the environment or how the projector is. |
|
Environmental notice for customers in the USA
Lamp in this product contains mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or see www.sony.com/mercury for additional information.
|
|
